AVB-STB
Automatic Band Saw Sharpening Machine
STB
Depending on the type and purpose of the cut, STB is designed for sharpening various saws of different shapes, widths, and thicknesses.
STB’s compact and robust sharpening unit ensures precise and consistent sharpening.
AIM
STB General Features:
• Automatic band saw sharpening machine for band widths up to 200mm.
• Dry sharpening.
With on/off switch
• Maximum tooth pitch of 60mm
• Fast and precise sharpening of NV, PV, and KV tooth shapes.
• Grinding head that moves on linear guide rails.
• Manual central lubrication.
• Manual saw holder front assembly movement.
• Optional circular saw (HSS) and gang saw sharpening attachments.
Capacity: On average, 30 band saw blades are sharpened per day.
STB Technical Specifications:
| Band saw width | 15-200mm |
| Tooth step | 5-60mm |
| Tooth depth | Maximum 30mm |
| Tooth shapes | PV, NV, KV, PU, NU |
| Chest angle | (-50°) (+20°) |
| Saw thickness | 0.6 – 3.2mm |
| Rate of progress | 45 teeth/min. |
| Number of engines | 2 |
| Sharpening stone outer diameter | Ø200mm |
| Sharpening stone hole diameter | Ø20mm |
| Sharpening stone thickness | 8/10/13mm |
| Operating voltage | 380V, 3 phase, 50-60Hz |
| Total power | ~1.5 kW |
| Net/gross weight | 350/375kg |
| Dimensions | 80*120*170cm |
